Rolled carton

Wrapped corrugated box is similar to 0210 box, the difference is that: 0210 box corrugation direction is parallel to the width of the box blank cardboard, while wrap type carton corrugation direction is parallel to the length of the cardboard; Rolled cartons are connected to the side of the box; the indentation line of the 0210 box inside and outside the cover is on a straight line, but the roll-up box is different.

In use, it is not like the 0210 carton box, which completes the entire process of carton making in a carton factory, and then fills the contents into the box after the user factory. Instead, it only passes the die-cut carton blank to the packaging user. The user uses an automatic packaging machine to put the contents and then rolls them into boxes.

Compared with the standard box, the package type carton is characterized by less material, and the carton and the contents are closely attached, which can realize high-speed automation.


Separate carton

Separated cardboard boxes can be divided into two or more during the circulation process, mainly to resolve the contradiction between mass production and small batch sales.

Separate cartons can be combined with various auxiliary materials on the basis of traditional standard cartons to make small cartons, or a new molding method.

The new type of separated carton generally adopts the combination of H-shaped middle partition and roll-up carton.

There are two types of N-type and F-type rolled cartons. Among them, Type F is more popular, and is mainly used in the packaging of shampoos and conditioners in plastic bottles, and in glass bottles.

The F-type roll-up carton can break the original 20 bottles into two 10-pack boxes. The compressive strength of the package is also improved, the cost of packaging materials is reduced, and it has a good promotion function.
